|Place of Origin:||Made in China|
|Brand Name:||TOTAL POOL|
|Minimum Order Quantity:||1 PC sample order acceptable|
|Packaging Details:||bubble film wrap+metal pallet|
|Delivery Time:||15-30 DAYS|
|Payment Terms:||L/C, T/T, Western Union, MoneyGram|
|Supply Ability:||1000 PCS / MONTH|
|Model:||TD1200||Usage:||Swimming Pool Filtration,water Treatment|
|Specificatons:||Dia.1200~3000mm (dia.48"~118")||Material:||Fibreglass And Resin|
|Diameter:||1200mm||Weight In Operation:||2500kg|
deep bed sand filter,
commercial sand filters
commercial Sand Filter for swimming pool filtration made of fibrelgass material
New spiral cover system which aids the operations of opening and closing. The air purge is built into the cover which can be efficient to release the air from the filter. The distance between the upper part of the sand layer and the diffuser head (''freeboard'') has been increased to ensure greater distribution of water in the filtration phase and avoid sand being spilt into the drain during backwash.
The specially designed hole in the sand filter can make the sand exchanging process more convenient and efficient. In the filtering process, the filtering effect of water can be observed through the perspective hole which is designed in the sand filter.
Commercial sand filter is used in larger size installations, such as commercial and communal swimming pool, aquatic park, aquariums and water treatment. On demand, filters with special heights can be manufactured. Filters with diameters greater than 2500 mm and 3000 mm will be transported in special vehicles.
|Model||Diameter (mm)||Height (mm)||Outlet (mm)||Filer area (m2)||Flow (m3/h)||Sand* (kg)||Gravel (1-2 mm)||weight in operation (kg)|
* Use only #20 white silica sand, size range0.4-0.8mm.
*Maximum working pressure: 2.5kg/cm² (35 psi ); maximum temperature: 50°C(122°F)
* filtration bed height 1m (3ft)
* on demand,filter with special heights can be manufactured.
* filters with diameters greater than Φ2500mm and Φ3000mm will be transported in special vehicles
* optional parts: side manhole, sightglass, air relief valve
