HONG KONG AUTUMN SOLAR TRADING CO., LIMITED
ISO qualified manufacturer / supplier for water fountain nozzles, colorful waterfall, musical fountain, mist fountain, LED lights, submersible pump etc.
 |
| Place of Origin: | made in China |
| Brand Name: | autumn solar |
| Certification: | ce |
| Model Number: | PU series |
| Minimum Order Quantity: | one pc |
|---|---|
| Price: | negotiable |
| Packaging Details: | carton |
| Delivery Time: | 15-20 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 pcs / month |
| Model: | PU-1072 | Name: | Chemical Dosing Pump |
|---|---|---|---|
| Structure: | Diaphragm Pump | Voltage: | 220V/50Hz |
| Output (LPH): | 0.47-15.77 LPH | Pressure: | 7 Bar / 4.2 Bar |
| Function: | Water Treatment | Place Of Origin: | Guangdong China |
| High Light: | swimming pool chlorine feeder,swimming pool dosing system |
||
pulsafeeder copy mechanically actuated diaphragm metering pump
FEATURES:
Easy installation and simple operation
Accurate measurement and adjustable flow rate
Strong anti-corrosiveness
Economical & practical
Metal strengthened diaphragm, long life
APPLICATIONS:
Counter osmosis,electrodialysis
Water circulating cooling
Purification of water & sewage treatment
Laboratory & testing-room
Other small-size measuring equipments
SPECIFICATIONS:
| model | Stroke per minute | Rated flow (L/H) | Maximum pressure (BAR) | Connection size (inch) | Motor power (W) | Weight (kg) | Voltage (V) |
| PU-47 | 7 | 0.47 | 7 | 1/2” outlet threaded link (provided with 1/4” inserting tube) | 3.5 | 3.63 | 220V single phase 50 Hz |
| PU-110 | 13 | 1.10 | 7 | 4.2 | |||
| PU-236 | 25 | 2.36 | 7 | 7.0 | |||
| PU-378 | 51 | 3.78 | 7 | 8.8 | |||
| PU-472 | 51 | 4.72 | 4.2 | 9.2 | |||
| PU-1072 | 70 | 10.72 | 4.2 | 9.2 | |||
| PU-1577 | 70 | 15.77 | 16 |
MATERIAL DETAILS:
| description | Standard material | Material for choice |
| Pump head | San | PVC / PE / 316S |
| Linking parts | PVC | PE / 316S |
| Valve seat diaphragm | Hypalon | Teflon / Vlton |
| gasket | teflon | |
| Valve ball | ceramic | teflon / 316S |
| Discharge tube | PE | 1/2” thread link |
| Suction tube | PVC | 1/2” thread link |
DIMENSION:
Contact Person: Ms Jenny Gan
Tel: 0086 13826267021
